Product Detail

Specifications

• Torque(6.0V): 22.0 kg-cm ( 305.5 oz/in)

• Torque(7.4V): 26.0 kg-cm ( 361.1 oz/in)

• Torque(8.4V): 30.0 kg-cm ( 416.6 oz/in)

• Speed: 0.16 sec (6.0V)│0.13 sec (7.4V)│

• Speed: 0.11 sec (8.4V)

• Operating Voltage：6.0 ~ 8.4 DC Volts

• Weight: 82 g (2.89 oz)

• Bearing Type：Ball Bearing x 2

• Motor Type：Coreless Motor

• Gear Type：Steel & Aluminum

• Operating Temperature：-10℃~60℃

• Working frequency：1520μs / 333hz

• Size：40.7 x 20.5 x 38.5 mm ( 1.60 x 0.81 x 1.52 in)

• Compatible with program box only
